Inlet valves or flaps are commonly used for ventilation in livestock buildings. By winding and unwinding a cable on a drum, the inlet valves are opened or closed gradually, ensuring optimal ventilation in case of negative pressure or excess heat.

  • For the best climate and animal welfare.
  • Flexible installation.
  • Multiple slides can be controlled at the same time.
  • Low-maintenance and low-noise.
  • Cost-effective solution.

KL300 MultiWinch

ArticleDescriptionT [Nm]n [rpm]P [VA]I [A]s [rev]m [kg]
P.KL300.1.024.08.LKL300 0.8 24VDC for winch drum / sprocket900,8 (0,4)72 (48)3,0 (2,0)0,25 - 1006,2
Article number
P.KL300.1.024.08.L
Description
KL300 0.8 24VDC for winch drum / sprocket
T [Nm]
90
n [rpm]
0,8 (0,4)
P [VA]
72 (48)
I [A]
3,0 (2,0)
s [rev]
0,25 - 100
m [kg]
6,2

Winch drum

ArticleDescriptionL [mm]B [mm]D1 [mm]D2 [mm]D3 [mm]m [kg]
P.LT1.B.D48.D25.01Belt winch drum D48 d25 B25 KL30042254825780,1
Article number
P.LT1.B.D48.D25.01
Description
Belt winch drum D48 d25 B25 KL300
L [mm]
42
B [mm]
25
D1 [mm]
48
D2 [mm]
25
D3 [mm]
78
m [kg]
0,1

GW motor gearbox

ArticleDescriptionT (50/60Hz) [Nm]L [mm]D [mm]P (50/60Hz) [kW]I (@ Δ) (50/60Hz) [A]I (@ Y) (50/60Hz) [A]m [kg]
P.GW10.3.230.13.LGW10 1.3 1ph 230V for winch drum100 / -1911240,09 / --1,1 / -21
P.GW10.3.400.13.LGW10 1.3 3ph 400V for winch drum100 / 801911240,09 / 0,110,9 / 0,90,5 / 0,521
Article number
P.GW10.3.230.13.L
Description
GW10 1.3 1ph 230V for winch drum
T (50/60Hz) [Nm]
100 / -
L [mm]
191
D [mm]
124
P (50/60Hz) [kW]
0,09 / -
I (@ Δ) (50/60Hz) [A]
-
I (@ Y) (50/60Hz) [A]
1,1 / -
m [kg]
21
Article number
P.GW10.3.400.13.L
Description
GW10 1.3 3ph 400V for winch drum
T (50/60Hz) [Nm]
100 / 80
L [mm]
191
D [mm]
124
P (50/60Hz) [kW]
0,09 / 0,11
I (@ Δ) (50/60Hz) [A]
0,9 / 0,9
I (@ Y) (50/60Hz) [A]
0,5 / 0,5
m [kg]
21

Mounting plate

ArticleDescriptionA [mm]H [mm]m [kg]
P.MP.GW.H.A100Mounting plate GW right angle A100 H1111001112,0
P.MP.GW.H.A122Mounting plate GW right angle A122 H1331221332,2
Article number
P.MP.GW.H.A100
Description
Mounting plate GW right angle A100 H111
A [mm]
100
H [mm]
111
m [kg]
2,0
Article number
P.MP.GW.H.A122
Description
Mounting plate GW right angle A122 H133
A [mm]
122
H [mm]
133
m [kg]
2,2

Cable winch drum

ArticleDescriptionL [mm]B [mm]D1 [mm]D2 [mm]D3 [mm]m [kg]
P.LT1.GW10Single cable winch drum GW10906350181182,8
Article number
P.LT1.GW10
Description
Single cable winch drum GW10
L [mm]
90
B [mm]
63
D1 [mm]
50
D2 [mm]
18
D3 [mm]
118
m [kg]
2,8

Encoder I-DE

ArticleDescriptionn [rpm]m [kg]
P.IDE.024.01I-DE 24V AC/DC digital/analogue Enc. built-in1,2 - 8,00,06
Article number
P.IDE.024.01
Description
I-DE 24V AC/DC digital/analogue Enc. built-in
n [rpm]
1,2 - 8,0
m [kg]
0,06

Potentiometer

ArticleDescriptionOhm [ohm]m [kg]
P.PM.500Potentiometer 500 ohm built-in5000,037
P.PM.1000Potentiometer 1000 ohm built-in10000,037
P.PM.5000Potentiometer 5000 ohm built-in50000,037
P.PM.10000Potentiometer 10 000 ohm built-in100000,037
P.PM.2000Potentiometer 2000 ohm built-in20000,037
Article number
P.PM.500
Description
Potentiometer 500 ohm built-in
Ohm [ohm]
500
m [kg]
0,037
Article number
P.PM.1000
Description
Potentiometer 1000 ohm built-in
Ohm [ohm]
1000
m [kg]
0,037
Article number
P.PM.5000
Description
Potentiometer 5000 ohm built-in
Ohm [ohm]
5000
m [kg]
0,037
Article number
P.PM.10000
Description
Potentiometer 10 000 ohm built-in
Ohm [ohm]
10000
m [kg]
0,037
Article number
P.PM.2000
Description
Potentiometer 2000 ohm built-in
Ohm [ohm]
2000
m [kg]
0,037

Potentiometer gear set

ArticleDescriptioni [-]m [kg]
P.PM.TWS.1,21.GW10Gear set 84.18.48.30 for GW101,210,12
P.PM.TWS.1,46.GW10Gear set 81.21.48.30 for GW101,460,12
P.PM.TWS.1,64.GW10Gear set 79.23.48.30 for GW101,640,11
P.PM.TWS.2,03.GW10Gear set 75.27.48.30 for GW102,030,11
P.PM.TWS.2,34.GW10Gear set 72.30.48.30 for GW102,340,10
P.PM.TWS.2,57.GW10Gear set 70.32.48.30 for GW102,570,10
P.PM.TWS.2,81.GW10Gear set 68.34.48.30 for GW102,810,13
P.PM.TWS.3,19.GW10Gear set 30.17.48.30 for GW103,190,10
Article number
P.PM.TWS.1,21.GW10
Description
Gear set 84.18.48.30 for GW10
i [-]
1,21
m [kg]
0,12
Article number
P.PM.TWS.1,46.GW10
Description
Gear set 81.21.48.30 for GW10
i [-]
1,46
m [kg]
0,12
Article number
P.PM.TWS.1,64.GW10
Description
Gear set 79.23.48.30 for GW10
i [-]
1,64
m [kg]
0,11
Article number
P.PM.TWS.2,03.GW10
Description
Gear set 75.27.48.30 for GW10
i [-]
2,03
m [kg]
0,11
Article number
P.PM.TWS.2,34.GW10
Description
Gear set 72.30.48.30 for GW10
i [-]
2,34
m [kg]
0,10
Article number
P.PM.TWS.2,57.GW10
Description
Gear set 70.32.48.30 for GW10
i [-]
2,57
m [kg]
0,10
Article number
P.PM.TWS.2,81.GW10
Description
Gear set 68.34.48.30 for GW10
i [-]
2,81
m [kg]
0,13
Article number
P.PM.TWS.3,19.GW10
Description
Gear set 30.17.48.30 for GW10
i [-]
3,19
m [kg]
0,10
