Sliding shutters with cable system
Sliding shutters with spooling system
●
HomeDrive SystemsDrive systems for poultry buildingsDrive systems for daylight controlDaylight control

Sliding shutters with cable system

How do I make a calculation?

We are happy to help you with making a calculation

Get in contact with us
Print this system (pdf)

Click here to create a PDF of the page

Download

Requirements for the right climate and well-being of poultry in buildings are becoming increasingly strict. A generous amount of daylight is generally seen as an important aspect of well-being for laying hens. Daylight can be controlled easily and very precisely by moveable shutters driven by a cable and drum.

  • For the right animal welfare.
  • Flexible installation.
  • Multiple slides can be controlled at the same time.
  • Low-maintenance and low-noise.
  • Cost-effective solution.

KL300 MultiWinch

ArticleDescriptionT [Nm]n [rpm]P [VA]I [A]s [rev]m [kg]
P.KL300.1.024.08.LKL300 0.8 24VDC for winch drum / sprocket900,8 (0,4)72 (48)3,0 (2,0)0,25 - 1006,2
Article number
P.KL300.1.024.08.L
Description
KL300 0.8 24VDC for winch drum / sprocket
T [Nm]
90
n [rpm]
0,8 (0,4)
P [VA]
72 (48)
I [A]
3,0 (2,0)
s [rev]
0,25 - 100
m [kg]
6,2

Belt drum

ArticleDescriptionL [mm]B [mm]D1 [mm]D2 [mm]D3 [mm]m [kg]
P.LT1.B.D48.D25.01Belt winch drum D48 d25 B25 KL30042254825780,1
Article number
P.LT1.B.D48.D25.01
Description
Belt winch drum D48 d25 B25 KL300
L [mm]
42
B [mm]
25
D1 [mm]
48
D2 [mm]
25
D3 [mm]
78
m [kg]
0,1

GW motor gearbox

ArticleDescriptionT (50/60Hz) [Nm]n (50/60Hz) [rpm]L [mm]D [mm]P (50/60Hz) [kW]I (@ Y) (50/60Hz) [A]I (@ Δ) (50/60Hz) [A]m [kg]
P.GW10.3.230.13.LGW10 1.3 1ph 230V for winch drum100 / -1,3 / -1911240,09 / -1,1 / --21
P.GW10.3.400.13.LGW10 1.3 3ph 400V for winch drum100 / 801,3 / 1,61911240,09 / 0,110,5 / 0,50,9 / 0,921
P.GW30.2.230.13.LGW30 1.3 1ph 230V for winch drum300 / -1,3 / -2201450,12 / -1,3 / --24
P.GW30.400.13.LGW30 1.3 3ph 400V for winch drum300 / 2401,3 / 1,61911450,18 / 0,220,7 / 0,71,2 / 1,225
Article number
P.GW10.3.230.13.L
Description
GW10 1.3 1ph 230V for winch drum
T (50/60Hz) [Nm]
100 / -
n (50/60Hz) [rpm]
1,3 / -
L [mm]
191
D [mm]
124
P (50/60Hz) [kW]
0,09 / -
I (@ Y) (50/60Hz) [A]
1,1 / -
I (@ Δ) (50/60Hz) [A]
-
m [kg]
21
Article number
P.GW10.3.400.13.L
Description
GW10 1.3 3ph 400V for winch drum
T (50/60Hz) [Nm]
100 / 80
n (50/60Hz) [rpm]
1,3 / 1,6
L [mm]
191
D [mm]
124
P (50/60Hz) [kW]
0,09 / 0,11
I (@ Y) (50/60Hz) [A]
0,5 / 0,5
I (@ Δ) (50/60Hz) [A]
0,9 / 0,9
m [kg]
21
Article number
P.GW30.2.230.13.L
Description
GW30 1.3 1ph 230V for winch drum
T (50/60Hz) [Nm]
300 / -
n (50/60Hz) [rpm]
1,3 / -
L [mm]
220
D [mm]
145
P (50/60Hz) [kW]
0,12 / -
I (@ Y) (50/60Hz) [A]
1,3 / -
I (@ Δ) (50/60Hz) [A]
-
m [kg]
24
Article number
P.GW30.400.13.L
Description
GW30 1.3 3ph 400V for winch drum
T (50/60Hz) [Nm]
300 / 240
n (50/60Hz) [rpm]
1,3 / 1,6
L [mm]
191
D [mm]
145
P (50/60Hz) [kW]
0,18 / 0,22
I (@ Y) (50/60Hz) [A]
0,7 / 0,7
I (@ Δ) (50/60Hz) [A]
1,2 / 1,2
m [kg]
25

Mounting plate

ArticleDescriptionA [mm]H [mm]m [kg]
P.MP.GW.H.A100Mounting plate GW right angle A100 H1111001112,0
P.MP.GW.H.A122Mounting plate GW right angle A122 H1331221332,2
Article number
P.MP.GW.H.A100
Description
Mounting plate GW right angle A100 H111
A [mm]
100
H [mm]
111
m [kg]
2,0
Article number
P.MP.GW.H.A122
Description
Mounting plate GW right angle A122 H133
A [mm]
122
H [mm]
133
m [kg]
2,2

Cable winch drum

ArticleDescriptionL [mm]B [mm]D1 [mm]D2 [mm]D3 [mm]m [kg]
P.LT2.GW10Double cable winch drum GW10 D50 D120902850181182,8
P.LT2.GWDouble cable winch drum GW20/30/40902850281482,8
Article number
P.LT2.GW10
Description
Double cable winch drum GW10 D50 D120
L [mm]
90
B [mm]
28
D1 [mm]
50
D2 [mm]
18
D3 [mm]
118
m [kg]
2,8
Article number
P.LT2.GW
Description
Double cable winch drum GW20/30/40
L [mm]
90
B [mm]
28
D1 [mm]
50
D2 [mm]
28
D3 [mm]
148
m [kg]
2,8

Encoder I-DE

ArticleDescriptionn [rpm]m [kg]
P.IDE.024.01I-DE 24V AC/DC digital/analogue Enc. built-in1,2 - 8,00,06
Article number
P.IDE.024.01
Description
I-DE 24V AC/DC digital/analogue Enc. built-in
n [rpm]
1,2 - 8,0
m [kg]
0,06

Potentiometer

ArticleDescriptionOhm [ohm]m [kg]
P.PM.500Potentiometer 500 ohm built-in5000,037
P.PM.1000Potentiometer 1000 ohm built-in10000,037
P.PM.5000Potentiometer 5000 ohm built-in50000,037
P.PM.10000Potentiometer 10 000 ohm built-in100000,037
Article number
P.PM.500
Description
Potentiometer 500 ohm built-in
Ohm [ohm]
500
m [kg]
0,037
Article number
P.PM.1000
Description
Potentiometer 1000 ohm built-in
Ohm [ohm]
1000
m [kg]
0,037
Article number
P.PM.5000
Description
Potentiometer 5000 ohm built-in
Ohm [ohm]
5000
m [kg]
0,037
Article number
P.PM.10000
Description
Potentiometer 10 000 ohm built-in
Ohm [ohm]
10000
m [kg]
0,037

Potentiometer gear set

ArticleDescriptioni [rpm]m [kg]
P.PM.TWS.3,19.GW10Gear set 30.17.48.30 for GW103,190,10
P.PM.TWS.3,19Gear set 30.17.48.303,190,10
P.PM.TWS.4,31.GW10Gear set 30.23.48.30 for GW104,310,10
P.PM.TWS.4,31Gear set 30.23.48.304,310,10
P.PM.TWS.4,88.GW10Gear set 30.26.48.30 for GW104,880,10
P.PM.TWS.4,88Gear set 30.26.48.304,880,10
P.PM.TWS.5,63.GW10Gear set 30.30.48.30 for GW105,630,10
P.PM.TWS.5,63Gear set 30.30.48.305,630,10
P.PM.TWS.7,20Gear set 68.34.30.487,200,13
Article number
P.PM.TWS.3,19.GW10
Description
Gear set 30.17.48.30 for GW10
i [rpm]
3,19
m [kg]
0,10
Article number
P.PM.TWS.3,19
Description
Gear set 30.17.48.30
i [rpm]
3,19
m [kg]
0,10
Article number
P.PM.TWS.4,31.GW10
Description
Gear set 30.23.48.30 for GW10
i [rpm]
4,31
m [kg]
0,10
Article number
P.PM.TWS.4,31
Description
Gear set 30.23.48.30
i [rpm]
4,31
m [kg]
0,10
Article number
P.PM.TWS.4,88.GW10
Description
Gear set 30.26.48.30 for GW10
i [rpm]
4,88
m [kg]
0,10
Article number
P.PM.TWS.4,88
Description
Gear set 30.26.48.30
i [rpm]
4,88
m [kg]
0,10
Article number
P.PM.TWS.5,63.GW10
Description
Gear set 30.30.48.30 for GW10
i [rpm]
5,63
m [kg]
0,10
Article number
P.PM.TWS.5,63
Description
Gear set 30.30.48.30
i [rpm]
5,63
m [kg]
0,10
Article number
P.PM.TWS.7,20
Description
Gear set 68.34.30.48
i [rpm]
7,20
m [kg]
0,13

Drive systems for daylight control

Chicken welfare in intensive livestock farming is getting more attention worldwide. Ensuring daylight entry is therefore an increasingly common practice. It helps save energy by reducing light consumption and contributes to livestock welfare. To maximise daylight entry and save energy, we offer the GW series in combination with a winch drum or the unique GXP10 drive for efficient roller blinds.

Daylight control
Daylight control
●
HomeDrive SystemsDrive systems for poultry buildingsDrive systems for daylight controlDaylight control

Sliding shutters with spooling system

How do I make a calculation?

We are happy to help you with making a calculation

Get in contact with us
Print this system (pdf)

Click here to create a PDF of the page

Download

Requirements for the right climate and well-being of poultry in buildings are becoming increasingly strict. A generous amount of daylight is generally seen as an important aspect of well-being for laying hens. Daylight can be controlled easily and very precisely by a drive with a guide tube.

  • For the right animal welfare.
  • Ideal control with dedicated drive.
  • Optimum force distribution when mounted in the middle of the building.
  • Low-maintenance and low-noise.
  • Cost-effective solution.

GXP10 motor gearbox

ArticleDescriptionT (50/60Hz) Nmn (50/60Hz) [rpm]P (50/60Hz) [kW]I (Δ) (50/60Hz) [A]I (Y) (50/60Hz) [A]m [kg]
P.GXP10.2.230.40.KBS.TGXP10-4.0 230V 1~ 50Hz for KBS Trop.iso100 / -4,0 / -0,18 / --1,5 / -11
P.GXP10.400.40.KBS.TGXP10-4.0 400V 3~ 50Hz for KBS Trop.iso100 / 804,0 / 4,80,18 / 0,221,2 / 1,20,7 / 0,711
Article number
P.GXP10.2.230.40.KBS.T
Description
GXP10-4.0 230V 1~ 50Hz for KBS Trop.iso
T (50/60Hz) Nm
100 / -
n (50/60Hz) [rpm]
4,0 / -
P (50/60Hz) [kW]
0,18 / -
I (Δ) (50/60Hz) [A]
-
I (Y) (50/60Hz) [A]
1,5 / -
m [kg]
11
Article number
P.GXP10.400.40.KBS.T
Description
GXP10-4.0 400V 3~ 50Hz for KBS Trop.iso
T (50/60Hz) Nm
100 / 80
n (50/60Hz) [rpm]
4,0 / 4,8
P (50/60Hz) [kW]
0,18 / 0,22
I (Δ) (50/60Hz) [A]
1,2 / 1,2
I (Y) (50/60Hz) [A]
0,7 / 0,7
m [kg]
11

Coupling bush GXP10

ArticleDescriptionD1 [mm]D2 [mm]L1 [mm]L2 [mm]m [kg]
P.KBS32.01.D19Coupling bush GXP tube Ø32x1.5; 25x25x1.54019118800,6
P.KBS50.01.D19Coupling to Tube Ø50mm GXP105019105700,4
P.KBS50.02.D19Coupling to Tube Ø50 Twinrol GXP105019100700,3
Article number
P.KBS32.01.D19
Description
Coupling bush GXP tube Ø32x1.5; 25x25x1.5
D1 [mm]
40
D2 [mm]
19
L1 [mm]
118
L2 [mm]
80
m [kg]
0,6
Article number
P.KBS50.01.D19
Description
Coupling to Tube Ø50mm GXP10
D1 [mm]
50
D2 [mm]
19
L1 [mm]
105
L2 [mm]
70
m [kg]
0,4
Article number
P.KBS50.02.D19
Description
Coupling to Tube Ø50 Twinrol GXP10
D1 [mm]
50
D2 [mm]
19
L1 [mm]
100
L2 [mm]
70
m [kg]
0,3

Top and bottom mounting bracket

ArticleDescriptionm [kg]
P.BL.02.GXP10GXP lower guide mounting bracket0,4
P.BL.04.GXP10GXP10 upper guide mounting bracket0,4
Article number
P.BL.02.GXP10
Description
GXP lower guide mounting bracket
m [kg]
0,4
Article number
P.BL.04.GXP10
Description
GXP10 upper guide mounting bracket
m [kg]
0,4

Cable chain 1.5m with connection set

ArticleDescriptionL [m]m [kg]
P.KRP.15.16.20Cable chain GXP 15x16mm 2.0m + mounting set2,00,6
Article number
P.KRP.15.16.20
Description
Cable chain GXP 15x16mm 2.0m + mounting set
L [m]
2,0
m [kg]
0,6

Power cable

ArticleArticle nameP max [W]
P.KAB.4.075Cable 4x0,75mm² GXP per meter (Power)1380
Article number
P.KAB.4.075
Article name
Cable 4x0,75mm² GXP per meter (Power)
P max [W]
1380

Drive systems for daylight control

Chicken welfare in intensive livestock farming is getting more attention worldwide. Ensuring daylight entry is therefore an increasingly common practice. It helps save energy by reducing light consumption and contributes to livestock welfare. To maximise daylight entry and save energy, we offer the GW series in combination with a winch drum or the unique GXP10 drive for efficient roller blinds.

Daylight control
Daylight control
