Sleeve bolt coupling D100 L80 S20 200 Nm

Name: P.SBK100.02.S20
SKU: P.SBK100.02.S20

Article number

P.SBK100.02.S20

Description

Db [inch]

Db [mm]

43,5

Type

S20

L [mm]

200

m [kg]

0,8

The sleeve bolt coupling connects the input shaft of a rack or gearcase to the drive tube of the ventilation or screening system.

Article	Description	Db [inch]	Db [mm]	Type	L [mm]	m [kg]
P.SBK100.S20	Sleeve bolt coupling D100 L80 S20 200 Nm	1	34,5	S20	80	0,4
2 P.SBK100.S20 11 Sleeve bolt coupling D100 L80 S20 200 Nm 12 13 P.SBK100.S20.jpg 14 10 CAT_P.SBK100.S20_2D.gif more info »
P.SBK100.02.S20	Sleeve bolt coupling D100 L80 S20 200 Nm	1	43,5	S20	200	0,8
2 P.SBK100.02.S20 11 Sleeve bolt coupling D100 L80 S20 200 Nm 12 13 P.SBK100.02.S20.jpg 14 10 CAT_P.SBK100.02.S20_2D.gif more info »
